Safety Belt Buckle - 2nd Row, without Inflatable Safety Belts: Notes
NOTE:
For information on Ford Color Coded Illustrations refer to COLOR-CODING - FORD
.
Exploded View
NOTE:
RH 40 percent shown in illustration, LH 40 percent and 60 percent inboard similar.
| Item | Service Part Number | Description | Tool Number | Material Name | Notes |
|---|---|---|---|---|---|
| 1 | 61348 | Inboard recliner cover | - | - | - |
| 2 | 60044 | Safety belt buckle | - | - | - |
| 3 | - | Safety belt buckle bolt (part of 60044) | - | - | 40 Nm (30 lb-ft) |
