Safety Belt Retractor - 2nd Row, Center: Removal

All seats

1. 1.

   Remove the 60 percent seat. REFER to Seating - 2nd Row .

1. 2.



Courtesy of FORD MOTOR COMPANY

1. 3.



Courtesy of FORD MOTOR COMPANY

1. 4.



Courtesy of FORD MOTOR COMPANY

1. 5.



Courtesy of FORD MOTOR COMPANY

1. 6.



Courtesy of FORD MOTOR COMPANY

Heated seat

1. 7.



Courtesy of FORD MOTOR COMPANY

All seats

1. 8.



Courtesy of FORD MOTOR COMPANY

Vehicles with inflatable belts

1. 9.

   Remove the safety belt buckle and inflator. Safety Belt Buckle and Inflator - 2nd Row, 60 Percent Seat .

All seats

1. 10.


   • Tighten to 3.5 Nm (31 lb-in).

Courtesy of FORD MOTOR COMPANY

1. 11.


   NOTE: To pivot the backrest, the inboard latch foot must be in the latched position.
   NOTE: Without inflatable safety belts shown in illustration, with inflatable safety belts similar.
   NOTE: At installation, make sure the safety belt is not twisted.
   • Tighten to 40 Nm (30 lb-ft).

Courtesy of FORD MOTOR COMPANY

1. 12.



Courtesy of FORD MOTOR COMPANY

1. 13.

   If equipped, remove the armrest. REFER to Seating - 2nd Row .

1. 14.

   If equipped.

Courtesy of FORD MOTOR COMPANY

Heated seat

1. 15.



Courtesy of FORD MOTOR COMPANY

All seats

1. 16.


   NOTE: Use care when separating the backrest cover from the hook-and-loop strip or the hook-and-loop strip can be torn from the backrest foam pad.

Courtesy of FORD MOTOR COMPANY

1. 17.

   Lift the backrest foam pad and remove the safety belt retractor bolt.
   • Tighten to 40 Nm (30 lb-ft).

Courtesy of FORD MOTOR COMPANY

1. 18.


   • Tighten to 48 Nm (35 lb-ft).

Courtesy of FORD MOTOR COMPANY

1. 19.



Courtesy of FORD MOTOR COMPANY

1. 20.



Courtesy of FORD MOTOR COMPANY
