Turbocharger - RH: Removal
WARNING: This page is about a different variant/trim than selected.
WARNING:
Before beginning any service procedure in this service information, refer to SAFETY WARNINGS
NOTE:
Whenever turbocharger air intake system components are removed, always cover open ports to protect from debris. It is important that no foreign material enter the system. The turbocharger compressor vanes are susceptible to damage from even small particles. All components should be inspected and cleaned, if necessary, prior to installation or reassembly.
- 1.
With the vehicle in NEUTRAL, position it on a hoist. REFER to Jacking and Lifting .
- 2.
Drain the cooling system. REFER to Engine Cooling .
- 3.
Remove the RH catalytic converter. REFER to Exhaust System .
- 4.
Remove the front subframe. REFER to Uni-Body, Subframe and Mounting System .
