Removal And Installation: Removal

Courtesy of CHRYSLER GROUP, LLC

Remove the rear spring link. Refer to LINK, SPRING, REMOVAL AND INSTALLATION .

As an installation reference, carefully mark the location of the isolator requiring removal on crossmember (around isolator can flange) using a marker or crayon.

Do not use a scratch awl to mark location.

Courtesy of CHRYSLER GROUP, LLC

1 - Adapters, Ball Joint Press C-4212-5

2 - Remover, Bushing Small 2026700170

3 - C-Support, Bushing Small, 2026800170-C

4 - Remover, Installer, Ball Joint 10140-3

5 - Press, Ball Joint C-4212F

NOTE:

Prior to using special tools, lubricate Press, Ball Joint (special tool #C-4212F, Press, Ball Joint) (E) threads to provide ease of use and promote tool longevity.

Assemble tools over isolator crossmember assembly as shown:
1. (special tool #C-4212-5, Adapters, Ball Joint Press)
2. (special tool #2026700170, Remover, Bushing Small)
3. (special tool #2026800170-C, Support, Bushing Small)
4. (special tool #10140, Remover, Installer, Ball Joint)
5. (special tool #C-4212F, Press, Ball Joint)
Tighten Press (E) screw-drive, pressing bushing out of crossmember and remove all tools.
