Lamp, Courtesy - Door, Flood: Installation

Courtesy of CHRYSLER GROUP, LLC

NOTE:

Driver side illustrated; passenger side similar.

Position the door flood lamp (1) to the door trim panel.
Gently press the lamp (1) into place until the integral retainer (2) engages the door trim panel completely.
Connect the door wiring harness lamp connector (3) to the lamp (1).
Install the door trim panel. Refer to PANEL, DOOR TRIM, REMOVAL AND INSTALLATION .
Connect the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), connect the IBS connector.
