Home >> Chrysler >> 2021 >> Voyager LXi, Gas >> Repair and Diagnosis >> Engine Performance >> Specifications >> Firing Order & Cylinder Identification >> Firing Order & Cylinder Identification >> V6 Engine >> 3.0L Turbo Diesel V6 Engine

3.0L Turbo Diesel V6 Engine

Engine Configuration Firing Order Cylinder Identification
3.0L Turbo Diesel 1-4-2-5-3-6
GC0040579
